Diva 3-Speed Fan and Light Control
Model # DVSCFSQ-LF-BW
Control ceiling fan and light independently with a paddle switch and slider in satin finishes for lighting and 3-speed fan adjustment.
Availability varies by country.
Configure
Model # DVSCFSQ-LF-BW
Product Details
Overview
The Diva fan and light control in satin colors provides independent operation of ceiling paddle fans and light kits from a single wallplate location. The paddle switch controls lights on/off while the slider adjusts fan operation through three quiet speeds, sliding to off when ventilation isn't needed. Controls up to 120W of LED/CFL or 240W of incandescent/halogen lighting. Engineered for quiet fan operation at all speeds, reducing motor hum common with standard dimmers. Rated for 1.5A ceiling paddle fans with integrated light kits. Requires separate wires at the wallbox for independent fan and light control with no neutral required. Single pole application. Coordinates with Claro wallplates for a unified appearance.
- Independent control operates fan and light separately from single location
- Three quiet fan speeds optimize comfort from gentle breeze to maximum cooling
- Quiet operation at all speeds eliminates motor hum for peaceful bedrooms
- 120W LED/CFL or 240W incandescent/halogen capacity handles most light kits
- Paddle switch and slider design matches Diva dimmers for consistent room appearance
- Dedicated fan control prevents motor damage compared to standard dimmers
- 10 year warranty with product registration
One Diva Fan and Light Control
Coordinating Claro wall plate sold separately
None
- No neutral wire required
- Single pole or Multi-Location
- Easy installation in as little as 15 minutes with existing wiring
Specifications & Documents
General Specifications
Color/Finish
Satin Brilliant White
Style & Type
On/Off Rocker with Captive Slider
Fan Control
Overall Dimensions
4.1 in x 2.1 in x 2.1 in (h x w x d)
Mounting Type
In-Wall
Wiring Type
Single-pole only
Wiring Requirements
No neutral wire required
Indoor / Outdoor
Indoor
Warranty
1 Year Limited Warranty
Electrical Specifications
Voltage
120 V~ 50/60 Hz
Ratings
1A LED
2A Incandescent/Halogen
1.5A Fan
